| Overall Parameter |
| overall length (mm) | 7495 |
| overall width (mm) | 2340 |
| overall height (mm) | 3035 |
| wheelbase (mm) | 4800 |
| Front/Rear overhang (mm) | 920 /1775 |
| approach angle/ departure angle (°) | 19/9 |
| (%)maximum gradability | 20 |
| front/rear tread (mm) | 1940/1800 |
| gross weight(kg) | 10800 |
| rated passenger | 39 |
| top speed (km/h) | 80 |
| Motor Parameter |
| Power motor model | YPQ220M-6 |
| Power motor type | Permanent magnet synchronous motor |
| Rated power / Peak power | 90kW |
| Max. torque | 1800N.m |
| Motor controller | WZL150 |
| Battery | Lithium lron Phosphate Battery |
| Battery capacity | 345v 200ah |
| Driving range | 80-100Km |
| Charging issue | Plug in |
| Charging time | 3H |
| storage battery | 100Ah*2 |
| Displacement (L) | 0 |
| Emission standard | 0 |
| Chassis Parameter |
| chassis model /manufacturer | 6660 |
| transmission | QJZJ505 |
| clutch | single dry diaphragm spring, Driven plate diameter φ325, Hydraulic long-distance manipulation, air booster. |
| front axle | “H” section, two fist type |
| driving axle | Fine grinding, single reduction gear. Ratio 5.13 |
| suspension | Leaf spring (front 3 / rear 4) |
| steering | Integral Power steering |
| braking | Dual circuit air brake, Energy storage spring parking brake, Drum brake. Automatic slack adjust Automatic Slack Adjuster, ABS |
| tyre | 8R22.5 |
| Other | Electric blast pump, auxiliary transducer, DC/DC |
| Body |
| body construction | Monocoque |
| interior Trim | Forming soft inner decoration, Polyurethane foam dashboard, spraying plastic handrail, PVC top and side board. |
| door and pump | Single inner-swing front door, double inner-swing rear door, pneumatic door pump |
| Windshield/side window | Whole view laminated front wind screen with window sunshade, sliding side window, without top window. |
| rearview system | Non-bilnd area iron-rack rear mirror, inner mirror. |
| Heating/defrosting | Electronic defroster |
| AC | Top fixed,16000Kcal/h |
| audio system | AM/FM cassette radiogram, MP3 |
| lights | Combination front and rear lights. LED inner lights |
| windscreen wiper | Scrape type of wiper with scrubber |
| seats | Plastic city bus seats, driver seat with three point safety belt. |
| floor leather | Anti-skid floor leather |
| lacquer | Solid lacquer |
| handle | Stainless steel |
| others | Colorful back guide monitor(two cameras) 4pcs of safety hammer 2pcs of auto extinguisher in motor compartment 2pcs of Fire extinguisher in the bus (4KG*2) Three level CAN bus Electric clock Battery automatic fire distinguishing system |
